Description:
CJBPZ-I all-in one vibration sensor integrates combines piezoelectric acceleration sensor with precision measuring circuit that composes high precision vibration measure system. The sensor can connect with DCS, PLC or other equioment directly. It is ideal for measuring vibration of fan, motor, water pump factory equipment etc.
Features:
Wide measure range
All material is Stainless steel
Various port type
Protection Grade: IP65
Performance Parameters:
|
Frequency Response
|
5-1000Hz
|
|
Natural Frequency of Vibration
|
10Hz
|
|
Measurement Range
|
Displacement Range 0-200um, 0- 500um, 0-1000um (opitional)
Speed Range 0-10.0mm/s,0-20.0mm/s, 0-100.0mm/s (optional)
|
|
Working Voltage
|
24V DC
|
|
Output Currency
|
4-20mA
|
|
Output Impedance
|
≤500Ω
|
|
Max Acceleration
|
10g
|
|
Measurement Direction
|
vertical or horizontal
|
|
Working Ambient Temperature
|
-40°C to 85°C,
|
|
Relative humidity
|
≤90%
|
|
Size
|
φ45×80（mm）
|
|
Weight
|
450g
|
|
Thread
|
M10×1.5
|
|
Protection Grade
|
IP65
|
